Auger Filling SS304 950kg Ton Bag Packaging Machine
Industrial Ton Bag Packaging Solution
This gross weight type 950kg bag packaging machine is specifically designed for the rubber industry and can handle various jumbo bag sizes including 300kg, 500kg, 1 ton, 1.5 tons, and 2 tons.
Machine Composition
The ton bag packaging machine integrates multiple systems including pneumatic bag-clamping, inflatable and gas recovery units, material feeding measurement control, hydraulic systems, and electric controls.
Control Panel Features
- Master Power Switch: Red button for main power supply control
- Touch Screen Interface: For operation control, parameter setting, and information display
- Emergency Stop Button: Immediate machine shutdown with safety reset procedure
Technical Specifications
| Parameter |
Specification |
| Quantitative Range |
400-1500 kg/bag |
| Control Accuracy |
Better than 0.2% |
| Packaging Speed |
10-30 tons/hour |
| Bag Type |
PP centralized packaging woven bag |
| Air Supply Pressure |
0.5±0.1 MPa |
| Air Consumption |
0.1 m³/min |
| Power Supply |
380V, 50Hz |
| Power Consumption |
5.0 kW |
| Working Temperature |
-15℃ to 45℃ |
| Material Construction |
316L stainless steel (contact parts), 304 stainless steel (remaining) |
Key Features
- High-precision weighing system with 0.02% accuracy sensor
- Dual valve material feeding control (fast, slow, and precision modes)
- Adjustable packaging range from 500-1200 kg
- Simple parameter setting and weighing calibration
- Advanced automation with stable performance
Service & Support
Documentation: English operational manual provided
Warranty: 12 months trouble-free performance guarantee from commissioning
After-sales Service: Free service for one year with spare parts availability (excluding human damage and consumables)
Main Machine Components
- Electric rotary valve
- Load cell
- Access platform
- Main weighing bracket
- Automatic release mechanism
- Automatic bag clamping mechanism
- Transition bin
- Pallet
- Chain conveyor
- Elevating cylinder
- Ladder and guardrail
- Solenoid valve control cabinet
- Explosion-proof control cabinet
Manufacturing Process Flow
Raw materials → Cutting → Drilling → Welding → Folding → Polishing → Rust Prevention → Paint Spraying → Assembling → Testing → Packaging and Transport → After Service
Machine Images
Packaging & Installation
The packaging machine is fully installed and tested before shipment. Each unit is packed in large wooden boxes within containers. Upon receipt, simply connect electrical wiring and air supply - no additional installation required.
